Pixhawk 2.4.8 Basic Flight Controller kit with GPS Module

PIXHAWK PX4 2.4.8 Flight Controller W/ SHOCK ABSORBER + UBLOX NEO-M8N GPS + GPS FOLDING ANTENNA BASE SET + Pixhawk Power Module + 433MHZ Telemetry + PPM The encoder combo kit gives you all the necessary control components for a quadcopter in one kit with an affordable price and good quality. Note: The package does not include Mini OSD. The PIXHAWK PX4 2.4.8 Flight Controller is a high-performance autopilot-on-module suitable for fixed-wing aircraft, multirotors, helicopters, cars, boats, and any other robotic platform that can move. It is targeted towards high-end research, amateur and industry needs, and combines the functionality of the PX4FMU and PX4IO. The universal vibration damping mount, or shock absorber, has a list of useful applications. This is free camera mounting to flight controller isolation. It absorbs vibration; the center-supported plate is ideal for sensitive electronics and cameras. The flush flat-bottom mounting allows bolt or tape style attachment. A new generation Ublox GPS NEO-M8N, with low power consumption and high precision, the ultimate accuracy is 0.6 meters, actually almost 0.9 meters, greater than the previous generation NEO-7N's 1.4-1.6 meter accuracy; it supports GPS/QZSS L1 C/A, GLONASS L10F, and the BeiDou B1 protocol, and more. The GPS Folding Antenna Base mount comes with a laser-cut adhesive pad to quickly attach your GPS module, while the mount itself can be fixed to your craft using the base plate M3 hole or the cross slides. The PIXHAWK PX4 2.4.8 Power Module is a simple way of providing your Pixhawk PX4 2.4.8 with clean power from a LiPo battery as well as current consumption and battery voltage measurements, all through a 6-pos cable. The Pixhawk PPM Encoder Module can be coded to a plurality of channels of PWM signal that output from the receiver to PPM composite signal output, connecting flight control with a single line. Package Includes: 1 x Pixhawk V2.4.8 Flight Board with Original Shell. 1 x 16GB TF card (IO firmware has been written). 3 x Connecting Cables. 1 x Buzzer Module. 1 x Pixhawk PPM Encoder Module. 1x JR plug 10P input end of the 100 mm cable. 1 x JR plug 4P output end of the 100 mm cable. 1 x Glass Fiber Flight Controller Anti-vibration/Shock Absorber Set. 1x NEO-M8N GPS Module with translucent shell. 2 x cables (APM/PIX). 1 x GPS Folding Base Antenna set. 1 x APM 2.5.2/2.6/2.8 Pixhawk Power Module. 2 x 3.5 dBi antennas. 1 x 3DR Radio Telemetry with the case (Tx and Rx). Features: Pixhawk V2.4.8 Flight board: 1. The advanced 32-bit ARM Cortex-M4 high-performance processors can run the NuttX RTOS real-time operating system. 2. 14 PWM/servo outputs. 3. Bus interface (UART, I2C, SPI, CAN). 4. The integrated backup power and backup controller fail; the primary controller fails over to the backup control, which is safe. 5. Provide automatic and manual modes. 6. Provide redundant power input and failover. 7. Multicolor LED lights. 8. Provide a multi-tone buzzer interface. 9. Micro SD recording flight data. Processor: 1. 32bit STM32F427 Cortex M4 core with FPU. 2. 168 MHz. 3. 128 KB RAM. 4. 2 MB Flash. 5. 32-bit STM32F103 failsafe co-processor. Sensors: 1. ST Micro L3GD20H 16-bit gyroscope. 2. ST Micro X4HBA 303H 14-bit accelerometer/magnetometer. 3. Invensense MPU 6000 3-axis accelerometer/gyroscope. 4. MEAS MS5607 barometer. Interfaces: 1. 5x UART (serial ports), one high-power capable, 2x with HW flow control. 2. 2x CAN (one with an internal 3.3V transceiver, one on the expansion connector). 3. Spektrum DSM / DSM2 / DSM-X® Satellite compatible input. 4. Futaba S.BUS® compatible input and output. 5. PPM sum signal input. 6. RSSI (PWM or voltage) input. 7. I2C. 8. SPI. 9. 3.3 and 6.6 V ADC inputs. 10. Internal micro USB port and external micro USB port extension. Glass Fiber Flight Controller Anti-vibration/Shock Absorber Set: 1. Color: Black 2. Material: Glass fiber 3. Suit for different open-source flight controller, like APM 2.5/2.6/2.8, KK, MWC, and Pixhawk 2.4 Packaging Details: 1. Package Weight: 24 gm. 2. Upper Frame size: 90 x 60 x 2 mm (LxWxH). 3. Lower Frame Size: 100 x 70 x 2 mm (LxWxH). 4. Shock absorber height: 10 x 12 mm (DxH). NEO-M8N GPS Module: 1. Receiver type: 72-channel Ublox M8 engine. 2. GPS/QZSS L1 C/A, GLONASS L10F, BeiDou B1. 3. SBAS L1 C/A: WAAS, EGNOS, MSAS. 4. Galileo-ready E1B/C (NEO-M8N). 5. Nav. update rate 1 Single GNSS: up to 18 Hz. 6. Concurrent GNSS: up to 10 Hz. 7. Position accuracy: 2.2 m CEP. 8. Acquisition 2 Cold start: 26 s. 9. Aided starts: 2 s. 10. Reacquisition: 1.5 s. 11. Sensitivity2 Tracking & Nav: –167 dBm. 12. Cold start: –148 dBm. 13. Hot starts: –156 dBm. 14. Assistance: AssistNow GNSS Online. 15. Assist Now GNSS Offline (up to 35 days) 3. 16. Assist Now Autonomous (up to 6 days). 17. OMA SUPL & 3GPP compliant 18. Oscillator TCXO (NEO-M8N/Q). 19. Crystal (NEO-M8M). 20. RTC crystal built-in. 21. Noise figure on-chip LNA (NEO-M8M). Extra LNA for. 22. lowest noise figure (NEO-M8N/Q). 23. Anti-jamming active CW detection and removal. 24. Extra onboard SAW bandpass filter (NEO-M8N/Q). 25. Memory ROM (NEO-M8M/Q) or Flash (NEO-M8N). 26. Supported antennas: active and passive. 27. Odometer travelled distance. 28. Data logger for position, velocity, and time (NEO-M8N). GPS Folding Base Antenna set: 1. Material: CNC Aluminum alloy, carbon glass fiber rod 2. Mounting rod diameter: 4 mm 3. length of rod: 14 cm. 4. GPS plate diameter: 40 mm. 5. Base plate diameter: 35 mm 6. Mounting hole spacing: 16-35mm 7. Weight: 20g 8. Colour: Anodised black 9. Note: Adhesive Pad is not included. APM 2.5.2/2.6/2.8 Pixhawk Power Module V1.0: 1. Max input voltage: 28V 2. Max current sensing: 90A 3. Voltage and current measurement configured for 5V ADC 4. Switching regulator outputs 5.3V and 3A max 5. 6-pos DF13 cable plugs directly to APM 2.5’s ‘PM’ connector 6. Support 6S battery. 433 MHz Radio Telemetry: 1. Very small size 2. Lightweight (under 4 grams without antenna) 3. Available in 433 MHz 4. Receiver sensitivity to -121 dBm 5. Transmit power up to 20 dBm (100 mW). 6. Transparent serial link 7. Air data rates up to kbps 8. The range of approximately 1 mile 9. MAVLink protocol framing and status reporting 10. Frequency hopping spread spectrum (FHSS) 11. Adaptive time division multiplexing (TDM) 12. Support for LBT and AFA 13. Configurable duty cycle 14. Built-in error-correcting code (can correct up to 25% data bit errors) 15. A demonstrated range of several kilometers with a small Omni antenna 16. Can be used with a bi-directional amplifier for even more range 17. Open-source firmware 18. AT commands for radio configuration 19. RT commands for remote radio configuration 20. Adaptive flow control when used with APM 21. Based on the HopeRF HM-TRP radio module, featuring a SiLabs Si1000 RF microcontroller. Pixhawk PPM Encoder Module: 1. Support the input channels: 8. 2. Output: PPM SUM × 1 / MUX × 1. 3. Dimensions: 28 x 19 x 5 mm. 4. Weight: 12 gm. (containing all the input and output wires).
